• Intel® Core™ Processors Series 3 with a Built-In NPU for AI Applications
• 1 x 2.5GbE, 4 x GbE Ports for IoT Devices Connectivity
• Type-C DP for Portable Display
• One Cover for Expansion Simplifies Module Installation
• Built-in Watchdog and Smart Power Management
• M12 Model for Robust Connection
• Front Tray for Coin-cell Battery Replacement
• Optional BBU for Emergency Circumstances
• Intel® Core™ 7 processor 350 up to 4.8 GHz (P-Core)
• Intel® Core™ 5 processor 320 up to 4.6 GHz (P-Core)
• Intel® Core™ 3 processor 304 up to 4.3 GHz (P-Core)
*2 x P-core + 4 x LP E-core for Core 7 350 and Core 5 320
*1 x P-core + 4 x LP E-core for Core 3 304
**Processor Base Power (TDP) is 28W
Intel® Graphics
1 x DDR5-6400 SO-DIMM up to 64 GB (In Band ECC Support)
1 x TPM 2.0 (Comply with FIPS 140-3)
Auto reset for unresponsive system
• 1 x HDMI® Output
• 1 x DVI-D Single-Link supports VDM
• 1 x USB Type-C DP output
1 x Line-out, 1 x Mic-in
• 1 x 2.5GbE from Intel I226-LM via RJ-45 or M12 X-code
• 4 x GbE from Marvell Ethernet Switch via RJ-45
*3 x GbE via M12 X-code (optional)
2 x USB 3.2, 2 x USB 2.0
6 x DI (0-60VDC), 4 x DO (12VDC/100mA), 1 x Isolated DO
(external 12V/1A support)
2 × COM support RS-232/422/485 ports
2 x CAN FD
• 1 x 12VDC/1A Out
• 1 x External Standby Control
• 2 x M.2 3042/3052* Key B for WWAN with dual Nano SIM support
• 1 x M.2 2230 Key E for Wi-Fi/BT
* One slot shares with one Mini PCIe
• 1 x Mini PCIe* (full-size w/ USB 2.0 only)
* One slot shares with one M.2 3042/3052
2 x M.2 2280 Key M for NVMe SSD
DC 9-60V (nominal power input DC 12V/24V/48V) via 3-pin terminal block or M12 K-code
2 x DC 24V/1A via 8-pin terminal block
OCP, OVP, surge protection, reversed polarity protection
Ignition detection, Smart Power Management
Removable front tray for RTC coin cell battery
Optional battery kit for up to 5 minutes of emergency backup time
(Battery charging Temp. 0°C ~ 45°C and discharging Temp. -10°C ~ 60°C)
* BBU backup time varies depending on actual overall system power consumption and battery is required to be charged before being used for system power backup
** Operating temperature will be limited within -10°C and 50°C with the battery kit installed.
Windows 11 IoT Enterprise LTSC, Ubuntu 24.04 LTS or above
-40°C ~ 70°C (-40°F ~ 158°F) with 0.6 m/s airflow
*Operating temperature varies by accessories installed.
-40°C ~ 80°C (-40°F ~ 176°F)
10% RH – 90% RH (non-condensing)
• IEC 60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
• MIL-STD-810H, Method 514.8, Procedure I, Category 4
MIL-STD-810H, Method 516.8, Procedure I, trucks and semi-trailers=15G (11ms)
CE, FCC Class A, UKCA, E-Mark, EN 62368-1* EN 50155* EN 45545-2 (R25), CISPR 25*
*On going
Aluminum Alloy with Fanless Design
9 x SMA connector panel mount hole
Wall mounting
• RJ-45 model: TBD
• M12 model: TBD
250 x 160 x x 55 mm (9.85 x 6.30 x 2.17 in.)
IP40
VBOX-3631(-M12X)-zz-zzz (M12X=w/ M12 X-coded connectors)
zz-zzz=C7-350=Intel® Core™ 7 Processor 350
zz-zzz=C5-320=Intel® Core™ 5 Processor 320
zz-zzz=C3-304=Intel® Core™ 3 Processor 304
Intel® Core™ Series 3 Edge AI Computer
Made in Taiwan
DDR5 SO-DIMM 8/16/24GB, -40°C ~ 85°C
M.2 2280 NVMe SSD 256GB~2TB, -40°C ~ 85°C
M.2 2230 Wi-Fi module, -40°C ~ 85°C
M.2 3042/3052 WWAN module, -40°C ~ 85°C
• M.2 2242 Key B GNSS module, -40°C ~ 85°C
• Mini PCIe GNSS module, -40°C ~ 85°C
• M.2 3042 Key B CAN module
• Mini PCIe CAN module, -40°C ~ 85°C
BAT-2300v2 (Operating Temp. : -20°C ~ 60°C (-4°F ~ 140°F)
24VDC, 160W
