9th Generation Intel® Core™ i7 / 8th Generation Intel® Core™ i7 / i5 / i3 CPU w/ 6 x RJ45 GbE (optional 4 x PoE Max. 100W) / 4 x COM / 1 x DP/ 1 x HDMI®/ 1 x DVI-I/ 4 x USB 3.2 Gen 1x1/ 9-48V Edge Computing
EBOX-7000 邊緣運算電腦，適用於採礦、機器視覺和製造等大規模的各種工廠自動化和工業物聯網（IIoT）控制系統。EBOX-7000，搭載第9代Intel Core i7和第8代Intel Core i7/i5/i3處理器，配備6個RJ45 GbE（可選配4個PoE，最大100W）。並具有TPM 2.0和2個DDR4 記憶體，最高可支援達64GB。此外，環境承受能力可連續保持較寬的工作溫度範圍（-40〜70ºC）。圖像顯示卡使用Intel®UHD Graphics 630，並提供最高解析度4096×2304 @ 24Hz（HDMI®）的影像輸出。
Intel Gen9 Core i7-9700TE (12M Cache 1.8GHz up to 3.8GHz)
Intel Gen8 Core i7-8700T (12M Cache 2.4GHz up to 4.0GHz)
Intel Gen8 Core i5-8500T (9M Cache 2.1GHz up to 3.5GHz)
Intel Gen8 Core i3-8100T (6M Cache 3.1GHz)
Intel Gen8 Celeron G4900T (2M Cache 2.9GHz)
2 x DDR4 2400/2666 MHz SO-DIMM up to 64GB
1 ~ 255 Level Reset
2.0
Intel® UHD Graphics 630 for i7/i5/i3, Intel® UHD Graphics 610 for G5900T
1
1
1 x DVI-I
(Single Link w/o Analog Video)
(DP 1.2) : 4096 x 2304@60Hz
(HDMI® 1.4b) : 4096 x 2304@24Hz
1
1
1
5 x Intel i210-AT
1 x i219 (iAMT9.5 w/ i5, i7 only) Gb/s Ethernet Controllers Onboard Support PXE and WOL
6 x RJ45 GbE
Optional 4 x PoE Max. 100W
4 x RS 232/422/485 (Auto Direction Control)
4 x USB 3.2 Gen
1 x 1 Ports
8 x DI (5~48VDC)
4 x DO (5VDC, 100mA)
Hot Swappable 2 x 2.5” Drive Bay for SATA Type HDD/SSD RAID 0, 1, 5 w/ External Accessibility via USB 3.2 Gen 1×1 when removed Patent No. : M601447 – Removeable Storage Device
1 x M.2 M key 2280 slot supports NVMe and SATA SSD *Thermal heatsink is required for M.2 storage. Please contact sales window for more information.
Riser card w/ 1 x PCIe x 16 slot
(1 x PCIe 3.0 x16 interface w/ 1 x ATX 6 Pin Power Output)
Optional riser card w/ 2 x PCIe x16 slot (2 x PCIe 3.0 x8 interface w/ 1 x ATX 6 Pin Power Output)
*Supports up to 185mm in length and 112mm in height PCIe cards
*Maximum power supply from PCIe slot and ATX 6 pin combined @ 150W when DC power source is above 15V
*DC 15V or above power source is suggested when graphics cards are installed
2 x Full Mini-PCle Slots
1x M.2 A-E Key 2230 slot, 1 x M.2 B Key 3042 slot w/ 2 x SIM Card Sockets for WWAN
Patent No. : M592609 – Automatic SIM Card Detection
9V – 48V DC Power Input
Automatics Recovery Short Circuit Protection
Vehicle Power Ignition for Variety Vehicle
Power off Delay Time Setting by BIOS and Software
Internal Battery Kit for 10 Mins Operating
(Optional and cannot be installed with PoE module)
*UPS backup time varies depending on actual overall system power consumption. Patent No. : M447854 – Build-in Battery
260(L) x 250(W) x 137(H) mm
Aluminum Alloy
7600g (Barebone)
Wall-mount
10% RH – 90% RH (non-condensing)
-40°C ~ 70°C, with SSD and ambient w/ air flow 0.6m/s
(System only, not including PCIe cards)
-20°C ~ 60°C with BAT-5200-E1 Battery Kit
*Operating temp. spec of PCIe cards installed affects overall system operating temp. spec
-40°C ~ 80°C
CE, FCC Class A, RoHS (Self declaration)
EBOX-7000xyy-zz (x= P= w/PoE, x= Empty= w/o PoE, yy= E1= w/1 x PCIe x16 interface, yy= E2= w/2 x PCIe 3.0 x8 interface, zz= i7R= i7-9700TE, zz= i7= i7-8700T, zz= i5= i5-8500T, zz= i3= i3-8100T, zz= C1= G4900T)
Intel 9th Gen Core i7/ Intel 8th Gen Core i7/i5/i3 CPU w/ 6 x RJ45 GbE (optional 4 x PoE Max. 100W) / 4 x COM / 1 x DP/ 1 x HDMI®/ 1 x DVI-I/ 4 x USB 3.2 Gen 1×1/ 9-48V Edge AI GPU Computing
Made in Taiwan
DDR4-2933 MHz SO-DIMM, 4GB~32GB, 0~70°C/-40~85°C
M.2 2280 B-M key NVMe TLC -40~85°C 64GB~1TB w/ Heatsink
M.2 2280 B-M key SATA TLC -40~85°C 64GB~1TB w/ Heatsink
2.5 inch SATA TLC -40~85°C 64GB~2TB
GTX 1650 4GB GDDR5 w/ 1 x DP1.4a, 1x HDMI® 2.0b, and 1x DVI-D Dual Link
WiFi M.2 2230 A-E key module
M.2 3042 B key 5G<E module
MiniPCIe GPS module
MiniPCIe CAN Bus module
BAT-5200-E1 Battery Kit, 5200m/h, -30~60°C, discharge -20~60°C, operating about 10 mins
280W/24V power adapter
