NXP® i.MX 8 QuadXPlus Automotive Grade SoC/ On-board LPDDR4 3GB/ On-board eMMC 5.1 32GB/ 1 x GbE/ 2 x RS-232/ 1 x DVI-D Single-Link/ 2 x USB 3.2
產品特色
產品介紹
IBOX-500 is an ultra-compact fanless in-vehicle Computer with 5G or LTE connectivity. It utilizes NXP i.MX 8QuadXPlus Automotive AEC-Q100 Grade 3 Processor up to 1.2 GHz. IBOX-500 features an ultra-compact design that can easily fit into restricted spaces. As robust connectivity, the system can select 5G, LTE, GPS, and Wi-Fi /Bluetooth by M.2 modules. It is the perfect solution for the digital cluster, intelligent cockpit, and fleet management. Furthermore, it features smarter vehicle power Ignition and can also effectively support cars in extreme weather and operating conditions, such as snowplows, Trucks, Buses, taxis, and Forklifts.
SYSTEM
Processor
NXP i.MX 8QuadXPlus Automotive SoC (AEC-Q100 Grade 3)
Integrated 4 x Arm Cortex@-A35 Cores Up to 1.2 GHz
1 x Am Cortex@-M4F Core Up to 264 MHz
Chipset
N/A
Memory
On-board LPDDR4 3 GB
Sensor
Built-in Accelerometer, Gyroscope, and Magnetic Sensor
Watchdog
1 ~ 255 Level Reset
GRAPHICS
Graphics Engine
CPU 1 x GC7000Lite with 4 x Vec4 shader cores
(16 execution units)
DVI-D
1 x Single Link (SINTRONES proprietary pin define)
Max Resolution
Max Resolution (DVI-D Single Link) : 1920x 1080 @60Hz
ETHERNET
LAN
1 x RJ-45 for GbE
I/O
Serial Port
1 x RS-232
1 x RS-232/422/485
USB
2 x USB 3.2 5 Gbps
1 x USB 2.0 OTG
DIO
8x DI (5~60VDC)
4 X DO (5VDC, 100mA)
STORAGE
Type
Onboard eMMC 5.1 32 GB
1 x Micro SD Slot
EXPANSION
M.2
1 x M.2 3042/3052 Key B for WWAN w/ 1 x nano SIM Slot
1 x M.2 2242 Key B for GPS
1 x M.2 Key A-E for Wi-Fi
POWER
Power Input
9V -60 V Power Input
Power Protection
Automatics Recovery Short Circuit Protection
Power-off Delay Control
Vehicle Power Ignition for Variety Vehicle
Power Off Control
Power off Delay Time Setting by Software
MECHANICAL
Dimension
214(L) x 150(W) x 43(H) mm
Weight
1,000g (Barebone)
Construction
Steel
Mounting
Wall-mount
ENVIRONMENT
Relative Humidity
10% RH – 90% RH (non-condensing)
Operating Temp.
-40°C ~ 70°C
Storage Temp.
-40°C ~ 85°C
Vibration & Shock
IEC 60068-2-64, Random, 2.5G@5~500Hz. 1hr/axis
MIL-STD-810G, Method 514.6, Procedure I, Cat.4, Operating
Operating: MIL-STD-810G, Method 516.6, Procedure, Trucks and semi-trailers=15G (11ms) with SSD
CERTIFICATION
Certification
CE, FCC, Class A, E-Mark, ECE R118
OPERATIONAL SYSTEM
Linux
Yocto Linux
ORDERING INFORMATION
Model No.
IBOX-500
Description
NXP i.MX 8QuadXPlus Automotive Grade SoC/ Onbaord LPDDR4 3GB/ Onboard eMMC 5.1 32GB/ 1 x GbE / 2 x RS-232/ 1 x DVI-D Single Link
/ 2 X USB 3.2
State of Origin
Made in Taiwan
Optional Accessory
Storage
MicroSD Card 64/128/256GB 3D TLC WT
Wi-Fi
M.2 2230 Key A-E/ IEEE 802.11 a/b/g/n/ac, Wi-Fi 6E
Modem
M.2 3042 Key B 5G & LTE Module
GPS
M.2 GPS Module
